Blue LED Pushbutton Switch 12VDC - Pre-Wired Latching

(No reviews yet) Write a Review
SKU:
SW-48-BL
  • Marinebeam LED Switch
  • Blue LED Push Button Switch Latching
  • 3-Conductor marine 22 AWG wiring included (Red, Brown, Black)
  • Blue LED Pushbutton Switch  12VDC - Pre-Wired Latching
  • Switch Dimensions
  • Switch Connections as wired
$7.99

Description

Stainless Steel recessed push-button On/Off switch with blue 12VDC LED indicator light.  A perfect complement to any 12V LED lighting project.  This latching type push button switch is pre-wired and ready for install.  It is pre-wired as a Normally Open latching switch, which will illuminate the blue LED light ring when the load is turned on. See pictures for wiring diagram.

Ideal for a wide range of 12VDC interior or exterior LED lighting projects.

  • Latching On/Off Push Button Switch
  • Pre-wired with 1M 3-conductor 22 AWG wire (color coded)
  • Silver Alloy Contacts
  • Maximum current 5A
  • IP67 water resistance
  • Blue LED ring is ON when load is ON
  • Stainless Steel
  • Panel Thickness 1mm to 12mm
  • Max. Switch Rating 5A
  • Cutout Required 16mm (5/8")
  • 12VDC only

Included parts:

  • Switch with 1 meter 3-conductor 22AWG cable
  • O-Ring
  • Locking Nut
  • Wiring Diagram
